ALP™ E2 SP
ALP E2M SF SP.jpg
ALP E2 S ARM SP.jpg
ALP E2 M ARM SP.jpgALP™ E2 SP
Adjustable Area & Site Light - Stocking Package
The ALP™ E2 Adjustable LED Area Light Stocking Package, crafted with precision engineering, provides customizable CCT and lumens. It includes three distribution options and lets you choose between an adjustable pole or slip fitter mounting kit. Effortlessly tailor your project for perfect illumination, ensuring every detail is highlighted.
Resources
Materials
- Die-Cast Aluminum
Ratings & Compliance
- FCC
- IK08
- IP65
Watts
- 80 w
- 120 w
- 150 w
- 200 w
- 240 w
- 300 w
CRI
- 80 CRI
Color / Finish
- Dark Bronze
Mounting
- Pole
- Slip Fitter
- Trunnion
- Wall Mount
Distribution
- Type 3
- Type 4
- Type 5
Lumens
- 12391 Lm
- 17313 Lm
- 20453 Lm
- 31581 Lm
- 37293 Lm
- 42419 Lm
Controls Options
- Daylight Sensor
- Occupancy Sensor
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
Dimming Protocol
- 0-10 V
Efficacy
- 125 lm/w
- 140 lm/w
- 150 lm/w
Lamp Life
- 100000 hrs
Lamp Source
- LED
Listings
- cULus
Voltage
- 120-277 V
Warranty
- 5 yr
Dimensions
- H: 3 In. L: 22.5 In. W: 11.2 In.
Product Type
- Exterior
