WPF-S™

Slim Full-Cutoff Wall Pack

The WPF-S™ slim full-cutoff wall pack provides high-performance outdoor illumination in a familiar form factor. Constructed with two-piece die-cast aluminum, the WPF-S™ offers field selectable lumens and CCT. An advanced polycarbonate lens provides uniform illumination and reduces glare when compared to traditional lighting sources.

Specification Sheet

Resources

CCT

  • Field Selectable CCT
  • 3000K
  • 4000K
  • 5000K

CRI

  • 70 CRI

Color / Finish

  • Dark Bronze

Controls Options

  • Photocell

Dimensions

  • H: 9.6 In. L: 13.1 In. W: 3.8 In.
  • L: 13.2 In. W: 5.0 In.

Dimming Protocol

  • 0-10 V

Distribution

  • Type III

Efficacy

  • 148 lm/w
  • 149 lm/w

Emergency Options

  • Integral EM Battery

Lamp Life

  • 50000 hrs

Listings

  • UL
  • cUL

Lumens

  • 3404 Lm
  • 5032 Lm
  • 6258 Lm
  • 7252 Lm
  • 9089 Lm
  • 9620 Lm
  • 12516 Lm
  • 14900 Lm

Materials

  • Die-Cast Aluminum
  • Polycarbonate

Mounting

  • Wall

Ratings & Compliance

  • ANSI C136.31
  • Wet

Voltage

  • 120-277 V
  • 347-480 V

Warranty

  • 5 yr

Watts

  • 23 w
  • 34 w
  • 42 w
  • 49 w
  • 61 w
  • 65 w
  • 84 w
  • 100 w

Weight

  • 4.8 lbs

Product Type

  • Exterior
