SL™ Series

Architectural Edgelit Surface Linear

The SL™ Series Linear Edgelit panel is the ideal surface-mounted fixture for a wide variety of applications. With two aperture sizes and a visual comfort prismatic lens, the SL™ Series offers uniform illumination without sacrificing high performance. The thin profile driver is integrated inside the fixture, leaving no bulky driver box and creating a simple, easy installation process. The extruded aluminum frame provides strength and durability, ensuring reliable and consistent performance.
Specification Sheet

Resources

** IMPORTANT NOTE **
The below SKUs are hidden from the website UI
** DO NOT DELETE THE BELOW **

SL4-4-L-C-U-D-SK
SL4-6-L-C-U-D-SK
SL4-90CRI

Beam Angle

  • 110

CCT

  • Field Selectable CCT
  • 3000K
  • 3500K
  • 4000K

CRI

  • 80 CRI
  • 90 CRI

Color / Finish

  • White

Dimming Protocol

  • 0-10 V

Efficacy

  • 84 lm/w
  • 90 lm/w

Emergency Options

  • Remote Inverter

Lamp Life

  • 54000 hrs

Listings

  • cULus

Lumens

  • 1680 Lm
  • 1800 Lm
  • 2520 Lm
  • 2650 Lm
  • 3400 Lm
  • 3600 Lm

Materials

  • Aluminum

Mounting

  • Surface

Ratings & Compliance

  • Damp
  • FCC

Shape

  • Linear

Voltage

  • 100-277 V

Warranty

  • 5 yr

Watts

  • 20 w
  • 30 w
  • 40 w

Product Type

  • Interior

Indoor Linear Collection
