Veil EX
Veil EXT Diffuser Lens Group.jpg
Veil EXT PC Diffuse 1ft.jpg
Veil EXT Optic Lens 1ft.jpg
Veil EXT Fixture and Track.jpg
Veil EXT Track.jpg
image005.jpgVeil EX
Linear Building and Facade Lighting
The Veil EX™ Architectural Building and Facade fixture is a robust exterior linear lighting solution designed for demanding commercial and architectural applications. Built with an anodized aluminum housing and sealed to IP65 standards, it offers flexible 60° adjustability, a wide range of beam distributions, including asymmetric and ultra-narrow optics, color temperatures from 2700K to 5000K. Available in 1' and 4' lengths with outputs up to 3,600 lumens, the Veil EX™ supports 0-10V dimming, delivering reliable, precise illumination.
Resources
Beam Angle
- 7x7
- 10x10
- 12x24
- 15x15
- 15x55
- 15x40
- 18x18
- 24x24
- 36x36
- 60x60
- 110
CCT
- 2200K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 80
- 90
Color / Finish
- Anodized Aluminum
Dimming Protocol
- 0-10 V
Efficacy
- 67
- 73
- 75
- 78
- 80
- 82
- 83
- 86
- 90
Lamp Life
- 50000
Listings
- cETLus
Lumens
- 670
- 730
- 750
- 780
- 800
- 820
- 830
- 860
- 900
- 2680
- 2920
- 3000
- 3120
- 3200
- 3280
- 3320
- 3440
- 3600
Materials
- Aluminum
Ratings & Compliance
- IP65
Shape
- Linear
Voltage
- 120-277 V
Warranty
- 5 yr
Watts
- 10
- 40
Product Type
- Architectural
- Exterior
